delro d650 White Delrin

d650 is delro electronics first 18650 device. No expense spared and not a single corner cut, every aspect of this device has been painstakingly designed. All components are bespoke and have undergone a lengthy trial and error process resulting in the most-accurate and bulletproof device possible. d650 is fully modular, capable of an endless range of customization, and is easy to disassemble, clean, and maintain.

d650 user guide here

Power handling:

• dicodes ec23d
• Dimensions:
• 77.8x51x22.5mm (23.5mm to buttons)

Case material:

• Media blasted Dupont Delrin

Panels:

• Matte acrylic

Buttons:

• Media blasted Delrin

C-frame:

• Passivated SS316L: media blasted SS or DLC black finish
• Aluminum: 7075 T7, hard-anodized black and type 2 anodized silver

T6 multitool  w/ keychain holder:

• D2 tool steel
• Finish: nickel plated
• Flush nut tool, T6 torx driver, 510 nut assembly tool
• Holder: media blasted delrin with chain loop

Power connections:

• Gold-plated stainless steel
• Gold-plated 464 Naval brass (battery +)

Screen cover:

• Scratch-resistant glass to seal electronics from dust, debris, and fingerprints.

Battery minus spring:

• Bi-directional spring contact made of gold-plated beryllium-copper (CuBe).

Power transfer PCB:

• A “power-to-board” PCB delivers stable and consistent current from the battery to the dicodes EC23d via M4 threaded nuts/bolts

Electronics:

Powering delro d650 is the Dicodes EC23d. This is the same time tested and proven board found in their insanely accurate and well-built tube mods (Dani Extreme v3), however our version has been highly customized for delro. Some of the changes include a faster response time, easier menu navigation and temp/power adjustment, and menus which provide a detailed breakdown of power loss and battery performance.

All electronic components have been designed in partnership with, and made by, Dicodes GmbH, a true expert in electronic design and production.  If any issues arise with the electronics, we have added a ZIF connector (similar to the connection a DNA/BF60 uses to attach the screen to the PCB) to the flexible membrane (button) board. This means all electronics can be easily removed and replaced. All electronics are covered by a 2Y warranty.

dicodes ec23 specs:

• 5 to 60W with one Li-Ion battery
• 3-button interface
• Adjustable battery discharge level 2.5-3V
• Up to 12V output voltage
• Up to 20A output current
• Temperature controlled vaping mode with various wire-types
• Mechanical MOD mode (electronically overload protected)
• 10 Power boost modes
• 10 Heater protection modes
• Atomizer resistance range 0.05 to 5 Ohms, total range
• Atomizer resistance range for 60W: 0.17-2.1 Ohms
• Reverse battery protection
• Versatile easy to use menu structure
• Individual user preferences selection
